Circular Polarity RFID Panel Antenna

S9028PCLF S9028PCRF

For 800 MHz ESMR and SMR or conventional applications, choose 4 element PC804N, 6 element
PC806N, or ten element PC8010N. The Laird Technologies PC804N, PC826N, and PC8210N are
also available in the 900 MHz GSM frequency band.

ESMR, SMR, CELLULAR, GSM, CONVENTIONAL YAGI ANTENNAS

For 800 MHz ESMR and SMR or conventional applications, choose 4 element PC804N, 6 element PC806N, or ten element PC8010N. The Laird Technologies PC804N, PC826N, and PC8210N are also available in the 900 MHz GSM frequency band.

FEATURES COMMON SPECIFICATIONS
All-welded unit construction Power handling – 200 Watts
No adjustments ever needed Elements – 1/4 in (.63 cm) 6061T6 aluminum rod;
Boom – 3/4 in (1.9 cm) 6061T6 aluminum channel
Waterproof design Mounting style – U-bolt; maximum mast diameter – 2-1/8 in (5.4 cm) pigtail – 19 in (48.3 cm)
Stainless steel hardware
Pigtail mounted N-female connector
MARKETS
WiMAX
