902-928 MHz 9 dBic CIRCULAR POLARITY PANEL
The Laird Technologies’ PAL90209H antenna is a circularly polarized panel antenna that provides reception and transmission of signals in the 902-928 MHz frequency band. Laird Technologies’ industry-renowned design methodology achieves maximum efficiency and performance across the entire frequency band.
Both VSWR and axial ratios are excellent and allow the user to achieve the maximum performance for an antenna of this type. The antenna is housed in a heavy duty radome enclosure that can be directly wall mounted. An optional articulating mount allows either wall or mast mounting. The antenna is offered with an integrated fixed connector with a variety of connector types.
|Extremely low VSWR and axial ratio||Distribution center|
|Weather and UV resistant radome||Airports and hospitals|
|Wide range of connector options||Transit terminals|
|Left hand and right hand CP versions||Conveyer belt|
